dspblok™ Legacy Modules

We will continue to provide customer support for our earlier dspblok DSP modules, however if you are developing a new design we suggest migrating to our most popular dspblok DSP Modules - which are based the fourth generation Analog Devices ADSP-214xx family of SHARC DSPs.



Our Legacy Modules are still available, but continue to be special order only.  Please contact us if you have a need for one of these earlier products.



The entire set of Legacy Product User Manuals and Datasheets and other supporting material can be found under Legacy Product Support.



      dspblok 21369 fpga r b 270x270                   dspblok 527 l b 440x441                  dspblok21369zx ice side1 270x318

dspblok™ 21369 + fpga

Variations:
  • dspblok 21369cy05
  • dspblok 21369cy25
  • dspblok 21369cy25 Ind Temp
  • JTAG Adapter







Special Order

dspblok™ 527

Variations:

  • dspblok 527
  • dspblok 527 Ind Temp
  • dspblock 527 + ICE
  • JTAG Adapter







Special Order

dspblok™ 21369zx

Variations:

  • dspblok 21369zx (400MHz)
  • dspblok 21369zx (333MHz Ext Temp)
  • dspblok 21369zx (400MHz 128M SDRAM)
  • dspblok 21369zx (512M SDRAM)
  • dspblok 21369zx with ICE
  • JTAG Adapter
  • Other options availble on request

Special Order



























dspstak a9238 l 270x270                   dspblok a9248 72dpi 270x346           p dspblok ad96k42 l 270

dspblok™ a9238

Variations:

  • dspblok a9238 (Xfmr Inputs)
  • dspblok a9238 (AD8138 Inputs)







Special Order

dspblok™ a9248

Variations:

  • dspblok a9248 (Xfmr Inputs)
  • dspblok a9248 (AD8138 Inputs)







Special Order

dspblok™ ad96k Family

Variations:

  • dspblok ad96k24
  • dspblok ad96k42
  • dspblok ad96k22
  • dspblok ad96k44
  • Variations include up to 4 input/outputs



Special Order

























 p dspblok ps usb l 224x163   p dspblok ps uart r 270   p dspblok io rtc r 270

dspblok™ ps-usb

dspblok ps-usb

P/N: A.08100

Special Order

dspblok™ ps-uart

dspblok ps-uart

P/N: A.08101A

Special Order

dspblok™ io-rtc

dspblok io-rtc

 P/N: A.08050

Special Order
